View In:   ArcGIS Online Map Viewer

Name: Streams

Display Field: GNIS_Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The National Hydrography Dataset (NHD) is a feature-based database that interconnects and uniquely identifies the stream segments or reaches that make up the nation's surface water drainage system. NHD data was originally developed at 1:100,000-scale and exists at that scale for the whole country. This high-resolution NHD, generally developed at 1:24,000/1:12,000 scale, adds detail to the original 1:100,000-scale NHD. (Data for Alaska, Puerto Rico and the Virgin Islands was developed at high-resolution, not 1:100,000 scale.) Local resolution NHD is being developed where partners and data exist. The NHD contains reach codes for networked features, flow direction, names, and centerline representations for areal water bodies. Reaches are also defined on waterbodies and the approximate shorelines of the Great Lakes, the Atlantic and Pacific Oceans and the Gulf of Mexico. The NHD also incorporates the National Spatial Data Infrastructure framework criteria established by the Federal Geographic Data Committee.Update October 2018

Service Item Id: c63a3c649c9f4761ba3f3537e2bd7ec0

Copyright Text: USGS National Hydrological Dataset (NHD) and Digital Line Graphs (DLG) WVGISTC

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 75000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 202158.02047572378
YMin: 4013095.542679524
XMax: 839519.5200773133
YMax: 4536120.89766263
Spatial Reference: 26917  (26917)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSDashDot
Color: [0, 169, 230, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: [GNIS_Name]
Use Coded Values: true
Symbol:
Color: [0, 112, 255, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 7
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 15000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• FDATE ( type: esriFieldTypeDate, alias: FDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: FDATE )
• RESOLUTION ( type: esriFieldTypeDouble, alias: Resolution, editable: true, nullable: true, defaultValue: null, modelName: RESOLUTION )
• GNIS_ID ( type: esriFieldTypeString, alias: GNIS_ID, editable: true, nullable: true, length: 10, defaultValue: null, modelName: GNIS_ID )
• GNIS_NAME ( type: esriFieldTypeString, alias: GNIS_Name, editable: true, nullable: true, length: 65, defaultValue: null, modelName: GNIS_NAME )
• LENGTHKM ( type: esriFieldTypeDouble, alias: LengthKM, editable: true, nullable: true, defaultValue: null, modelName: LENGTHKM )
• REACHCODE ( type: esriFieldTypeString, alias: ReachCode, editable: true, nullable: true, length: 14, defaultValue: null, modelName: REACHCODE )
• FLOWDIR ( type: esriFieldTypeDouble, alias: FlowDir, editable: true, nullable: true, defaultValue: null, modelName: FLOWDIR )
• FTYPE ( type: esriFieldTypeDouble, alias: FType, editable: true, nullable: true, defaultValue: null, modelName: FTYPE )
• FCODE ( type: esriFieldTypeDouble, alias: FCode, editable: true, nullable: true, defaultValue: null, modelName: FCODE )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: false, defaultValue: null, modelName: Shape.STLength() )
• PERMANENT_ ( type: esriFieldTypeString, alias: PERMANENT_, editable: true, nullable: true, length: 40, defaultValue: null, modelName: PERMANENT_ )
• WBAREA_PER ( type: esriFieldTypeString, alias: WBAREA_PER, editable: true, nullable: true, length: 40, defaultValue: null, modelName: WBAREA_PER )
• SHAPE_LENG ( type: esriFieldTypeDouble, alias: SHAPE_LENG, editable: true, nullable: true, defaultValue: null, modelName: SHAPE_LENG )
• MAINPATH ( type: esriFieldTypeDouble, alias: MAINPATH, editable: true, nullable: true, defaultValue: null, modelName: MAINPATH )
• INNETWORK ( type: esriFieldTypeDouble, alias: INNETWORK, editable: true, nullable: true, defaultValue: null, modelName: INNETWORK )
• VISIBILITY ( type: esriFieldTypeDouble, alias: VISIBILITY, editable: true, nullable: true, defaultValue: null, modelName: VISIBILITY )
• Shape_Le_1 ( type: esriFieldTypeDouble, alias: Shape_Le_1, editable: true, nullable: true, defaultValue: null, modelName: Shape_Le_1 )

Templates:

• Name: Streams
  Description:
  Prototype:
  VISIBILITY: null
  Shape_Le_1: null
  FDATE: null
  RESOLUTION: null
  GNIS_ID: null
  GNIS_NAME: null
  LENGTHKM: null
  REACHCODE: null
  FLOWDIR: null
  FTYPE: null
  FCODE: null
  INNETWORK: null
  PERMANENT_: null
  WBAREA_PER: null
  SHAPE_LENG: null
  MAINPATH: null

  Drawing Tool: esriFeatureEditToolLine

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
